Steel Casting UHP Extruded Carbon Graphite Electrode with Nipples
Steel Casting UHP Extruded Carbon Graphite Electrode with Nipples
Graphite electrode
The graphite electrode joint is an accessory of the graphite electrode. Graphite electrodes generally have higher requirements for joints. The joint generally has a special production process, which can be divided into (ordinary power graphite electrode joint, high-power graphite electrode joint and ultra-high power graphite electrode joint). Graphite electrode and joint have the advantages of high strength, not easy to break, good current flow.
RP HP UHP Graphite Electrods With Nipple
Grade: RP/HP/UHP
Diameter: 300/350/400/450/500/550/600/700/800mm
Length: 1500-2700mm
Nipple: 3TPI,4TPI
For arc furnace to steelmaking.
For mine thermoelectric furnace to production of ferroalloy, pure silicon, yellow phosphorus, copper ice, calcium carbide, etc.
resistance furnace.Graphite furnace, melting glass furnace and electric furnace for producing silicon carbide.
Notes of the use of graphite electrode
1.The electrode holder should be held in the place beyond the security line of the top electrode;otherwise, the electrode would be easily broken.the contact surface between the holder and the electrode should be cleaned up regularly to maintain a good contacting,the cooling jacket of the holder shall be avoided from water leakage.
2.Identify the reasons it there is gap in the electrode junction,do not use them until the gap is eliminated.
3.If there is falling off of nipple bolt when connecting electrodes,it is necessary to complete the nipple bolt.
4.The application of electrode should avoid of tilting operation, particularly , the gr.oup of connected electrodes should not be put horizontally so as to prevent from breaking.
5.When charging materials to the furnace,the bulk materials should be charged to the place of the furnace bottom,so as to minimize the impact of the large furnace materials on the electrodes.
6.The large pieces of insulation materials should be avoided of stacking on the bottom of the electrodes when smelting .so as to prevent from affecting the electrode use,or even broken.
7.Avoid of collapsing the furnace lid when rising or dropping the electrodes,which may result in electrode damage.
8.It is necessary to prevent the steel slag from splashing to the threads of the electrodes or nipple stored in the smelting site,which may damage the precision of the threads.
