Graphite Electrode UHP HP RP Grade for Electric Arc Furnace

Graphite Electrode UHP HP RP Grade for Electric Arc Furnace

Name:Graphite Electrodes
Description:The electrodes carry the electricity that heats electric arc furnaces, the vast majority steel furnaces. They are made from petroleum coke after it is mixed with petroleum pitch, extruded and shaped, then baked to sinter it, and then graphitized by heating it above the temperature (3000 °C) that converts carbon to graphite. They can vary in size up to 11 ft. long and 30 in. in diameter.
Usage:
An increasing proportion of global steel is made using electric arc furnaces, and the electric arc furnace itself is getting more efficient and making more steel per tonne of electrode

RP HP UHP Graphite Electrods With Nipple
Grade: RP/HP/UHP
Diameter: 300/350/400/450/500/550/600/700/800mm
Length: 1500-2700mm
Nipple: 3TPI,4TPI

Notes of the use of graphite electrode

1.The electrode holder should be held in the place beyond the security line of the top electrode;otherwise, the electrode would be easily broken.the contact surface between the holder and the electrode should be cleaned up regularly to maintain a good contacting,the cooling jacket of the holder shall be avoided from water leakage.
2.Identify the reasons it there is gap in the electrode junction,do not use them until the gap is eliminated.
3.If there is falling off of nipple bolt when connecting electrodes,it is necessary to complete the nipple bolt.
4.The application of electrode should avoid of tilting operation, particularly , the gr.oup of connected electrodes should not be put horizontally so as to prevent from breaking.
5.When charging materials to the furnace,the bulk materials should be charged to the place of the furnace bottom,so as to minimize the impact of the large furnace materials on the electrodes.
6.The large pieces of insulation materials should be avoided of stacking on the bottom of the electrodes when smelting .so as to prevent from affecting the electrode use,or even broken.
7.Avoid of collapsing the furnace lid when rising or dropping the electrodes,which may result in electrode damage.
8.It is necessary to prevent the steel slag from splashing to the threads of the electrodes or nipple stored in the smelting site,which may damage the precision of the threads.

EAF Graphite Electrode PRODUCT DESCRIPTION

Graphite electrode, mainly made of high quality petroleum coke and needle coke, coal tar pitch as binder, is prepared by calcination, compounding, kneading, pressing, roasting, graphitization and machining. According to the quality, it can be divided into regular power, high power and ultra high power.

APPLICATION

Ultra high power graphite electrode, mainly used in ultra high power steelmaking electric arc furnace (EAF).

High power graphite electrode, mainly used in high power electric arc furnace for steel making.

Regular power graphite electrode, mainly used in ordinary power electric furnace for steel making, silicon refining, yellow phosphorus and so on.

regular power Graphite Electrode ADVANTAGE

More than 15 years of factory experiences

Low consumption and more durable

Strict quality control from raw materials to finished products

Advanced production technology and strong technical force

Excellent sales at home and abroad, export to more than 20 countries and areas like Russia, Vietnam, India, Bangladesh, Turkey, Iran etc.
