UHP Grade Needle Coke Diameter 600mm 2400mm Length Graphite Electrode in Stock for Sale
UHP Grade Needle Coke Diameter 600mm 2400mm Length Graphite Electrode in Stock for Sale
High quality graphite electrode is our super featured products, diameter is from is Ø250-800mm.
Graphite electrode produced by our company has the advantages of low resistivity, high electrical
conductivity and thermal conductivity, good oxidation resistance, good thermal shock resistance,
high mechanical strength,easy to machine,etc.
Graphite electrode is widely used to smelt the steel,alloy steel and other metal or
nonmetal material in electric arc furnace.
* High density, high temperature resistance, high mechanical strength and strong chemical stability.
* The surface can be treated with anti-oxidation.
* Corrosion resistance, strong acid and alkali resistance.
* Excellent thermal shock resistance, electrical conductivity and thermal conductivity.
* Strong wear resistance and lubricating performance.
* Long service life.
HP (High Power Grade Graphite Electrodes) | ||||||
ITEM | UNIT | (M M)NOMINAL DIAMETER | ||||
200-300 | 350-400 | 450-500 | 550-600 | |||
BULK DENSITY | ELECTRODE | G/CM3 | ≥ 1.65 | ≥ 1.65 | ≥ 1.65 | ≥ 1.65 |
NIPPLE | ≥ 1.75 | ≥ 1.75 | ≥ 1.75 | ≥ 1.75 | ||
RESISTIVITY | ELECTRODE | μΩM | ≤6.5 | ≤6.5 | ≤6.5 | ≤6.5 |
NIPPLE | ≤4.0 | ≤4.0 | ≤4.0 | ≤4.0 | ||
BENDING STRENGTH | ELECTRODE | MPA | ≥12.0 | ≥12.0 | ≥12.0 | ≥12.0 |
NIPPLE | ≥16.0 | ≥16.0 | ≥16.0 | ≥16.0 | ||
ELASTIC MODULUS | ELECTRODE | GPA | ≤10.0 | ≤10.0 | ≤10.0 | ≤10.0 |
NIPPLE | ≤14.0 | ≤14.0 | ≤14.0 | ≤14.0 | ||
C.T.E. | ELECTRODE | 10-6/ºC | ≤ 2.2 | ≤ 2.2 | ≤ 2.2 | ≤ 2.2 |
NIPPLE | ≤ 2.2 | ≤ 2.2 | ≤ 2.2 | ≤ 2.2 | ||
ASH | % | ≤0.3 | ≤0.25 | ≤0.25 | ≤0.25
|
| Grade | Position | Specific Resistivity | Bulk density | Bending Strength | C.T.E | Elastic Modulus | Ash |
| RP | Body | ≤8.5 μΩ•m | ≥1.54g/cc | ≥8.5 Mpa | ≤2.4 x10-6/ºC | ≤9.3 Gpa | ≤0.4% |
| Nipple | ≤5.2 μΩ•m | ≥1.72g/cc | ≥17.0 Mpa | ≤2.3 x10-6/ºC | ≤14.0 Gpa | ≤0.4% | |
| HP | Body | ≤6.8 μΩ•m | ≥1.65g/cc | ≥11.0 Mpa | ≤2.3 x10-6/ºC | ≤12.0 Gpa | ≤0.3% |
| Nipple | ≤5.0 μΩ•m | ≥1.74g/cc | ≥18.0 Mpa | ≤2.1 x10-6/ºC | ≤16.0 Gpa | ≤0.2% | |
| UHP | Body | ≤6.0 μΩ•m | ≥1.66g/cc | ≥12.0 Mpa | ≤1.4 x10-6/ºC | ≤14.0 Gpa | ≤0.2% |
| Nipple | ≤4.0 μΩ•m | ≥1.77g/cc | ≥21.0 Mpa | ≤1.3 x10-6/ºC | ≤18.0 Gpa | ≤0.2% |
Advantages of Graphite electrode:
1. Reduce graphite electrodes lateral oxidation rate.
2. Lessen graphite electrodes consumption rate by 15%~20%.
3. Improve graphite electrodes cost efficiency.
4. It is a more cost-effective solution through reducing graphite electrodes purchasing cost by 10%~15%.
5. It is a production efficiency improving solution through reducing risk of graphite electrodes breakage and falling down.
